Surface grinding machines

for effective flat and shapes grinding

Surface grinders series BP are based on many years of experience the company M-MOOS with the overhauling and modernization of grinding machines for automatic production. They are designed for efficient and precise grinding of flat and contoured surfaces. The overall machine concept follow the company philosophy: To provide modern grinding machines and technologies that will meet the requirements of industrial production in the 21st century

Key features

+ Intuitive and simple operation

+ Fast dialog type programming

+ Sophisticated and easy cycles

+ Re-grinding to precise dimensions

+ Solid cast-iron construction machines

+ V-V Guideways guarantee high precision

+ Wide range of standard equipment

+ Comfortable operation and maintenance

Control system X-Solution

This 3rd generation of our own control system comes from the previous systems developed for the purpose of modernization of grinding machines for automatic production. X-Solution means a lot of new options, which is reflected in the standard equipment of whole system. It is based on a touch screen, intuitive interface and dialog type program making with sophisticated grinding cycles for different workpieces.



+ Intuitive and easy operation

+ Reduction of time delays

+ Faster program creation in few steps

+ Possibility to add a new customer´s cycles

+ Reliable system with on-line diagnostic

+ Sophisticated system management



Technical specification

Table type surface grinding machines

Model
BP-2550
BP-3060
BP-4080
Max. cross x longitudinal travel
350 x 900 mm
Spindle center height from table
600 mm
Grinding surface of table
250 x 500 mm
300 x 600 mm
350 x 800 mm
Table speed in longitudinal axis
1-25 m/min
Hydraulic motor (2AX only)
1.5 kW
Working feed
1240 mm/min
MPG step feed
0,001/0,005/0,01/0,05 mm
Grinding wheel dimension
355 x 38 x 127 mm
Grinding wheel cover dimension
450 x 155 mm
Max. height from table top to bottom of standard wheel
422 mm
Spindle motor
3.7 kW
Spindle speed
Stepless speed change 2400 rpm
Machine net weight
3000 kg
Machine gross weight
3600 kg

Column type surface grinding machines

Model
BP - 50100
BP - 50120
BP - 50150
BP - 60120
BP - 60150
BP - 60220
BP - 60250
Max. cross x longitudinal travel
560 x 1150
560 x 1350
560 x 1650
660 x 1350
660 x 1650
660 x 2350
660 x 2650
Spindle center height from table
700 mm
Grinding surface of table
500 x 1000
500 x 1200
500 x 1500
600 x 1200
600 x 1500
600 x 2200
600 x 2500
Table speed in longitudinal axis
1-25 m/min
Working feed
1240 mm/min
MPG step feed
0,001/0,005/0,01/0,05 mm
Grinding wheel dimension
(V.P x Š x I.P)- standard 355x50x127mm
Grinding wheel cover dimension
Standard: 450 x 155 mm
Max. height from table top to bottom of standard wheel
Stepless speed change 2400 rpm
Spindle motor
7.5(11) kW
Hydraulic motor
3.7 kW
Machine net weight
5800 kg
6100 kg
7000 kg
6500 kg
7400 kg
8900 kg
12500 kg
Machine gross weight
6900 kg
7500 kg
8500 kg
7900 kg
9000 kg
12000 kg
15600 kg
